• Collinear Load Test 280kg, 600pounds.
• Dual Voltage 12 or 24 VDC(optional).
• The Standard Voltage is 12VDC when Finished.
• MOV Provides Reverse Current Protection.
• Suitable For Wooden Door, Glass Door, Metal Door, Fireproof Door.
• LED Indicates the Door Status.
• Lock Status sensor(NO/NC/COM)
• Door Status sensor(NO/NC/COM)
• Anti-Residual Magnetism Designed.
• High Strength Material, Anodized Aluminum Housing.
• Design without Mechanical Failure.
• Increase the holding Force, Dual Insulative Housing.
| General | |
|---|---|
| Lock Size | 250Lx48.8Wx27.9H(mm) |
| Armature plate | 180Lx38.8Wx11H(mm) |
| Holding Force | 280kg (600Lbs) |
| Input Voltage | 12/24VDC Dual Voltage |
| Suitable for door | Wooden door, Glass door, Metal door, Fireproof door |
| Signal Output | Lock signal Status NO/NC/COM/+/- |
| Feature | Fail Safe, Timer delay, feedback signal, 12V/24VDC dual voltage |
| LED | Red shows unlocked; Green shows locked |
| Weight with packing(kg) | 1.9kgs |
